> I 22 geďntegreerde versterker



The I22 is a two x 80 watt integrated amplifier utilising our acclaimed proprietary UFPD power technology. It is designed to provide high power output with very low distortion and system control.

An optional DAC board is available for the I22, comprising three digital inputs for the upgrading of existing CD players via their digital outputs, and the streaming of music files from PCs and Macs. There is an isochronous USB-B input (16-24bit data at 44.1 to 96kHz), a TOSLINK connector (16-24 bit data at 44.1-192kHz) and SPDIF (16-24bit/44.1-192kHz). Specialised processing at the Isochronous USB-B input re-clocks the incoming data for reduced jitter and greater bit resolution through the DAC, optimising sound quality from music files.

Output Power: 2x 80W at 8Ω
2x 160W at 4Ω
 Analogue Inputs: 4 pair RCA (L & R)
Optional DAC Board: 1x USB-B input
1x Digital Optical input (1 TOSLINK)
1x Digital Coaxial input (1 RCA jack)
Input Impedance: 15kΩ
Analogue Record Output: 1 pair RCA (L & R)
 Pre Out: 1 pair RCA (L & R)
Output Impedance: RCA 94Ω
Frequency Response: 10Hz – 20kHz, -0.5dB
THD + N: < 0.05%, 20Hz – 20kHz, 10W at 8Ω
Signal to Noise:  -95dB
Power Consumption: Standby: 0.3W
Operate: 19W


Color:  black or titanium
Weight: 12,5kg
Width: 430 mm
Depth: 420 mm
Height: 106 mm


> I 22 documenten


> Brochure Engels

> Techniek Design Brief

> Manual Nederlands


> Reviews

Hifi.nl
Audio Video


incl DAC module (optie)


samen met de CD22 CD speler
