Gain: |
26dB |
|
Freq. Response: |
-3 dB at 1.5 Hz, -2
dB at 100 kHz |
|
Power Output: |
100 watts @ 8 ohms
200 watts @ 4 ohms |
|
Input Impedance: |
30 kohm balanced, 15
kohm unbalanced |
|
Distortion: |
0.01% @ 10 W,
.11% @ 100 W @ 1 KHz approx |
|
Output Voltage: |
+/- 43 volts |
|
Output Current: |
+/- 20 amps |
|
Damping factor: |
150 ref 8 ohms
nominal |
|
Slew rate: |
+/- 50 V/uS |
|
Output Noise |
150 uV unweighted
20-20 kHz |
|
Random noise floor: |
approximately 1 uV |
|
Dynamic range: |
155 dB (random noise
floor to peak output) |
|
Balanced CMRR: |
-60 dB @ 1 kHz |
|
DC offset: |
< 50 mv |
|
Power Consumption: |
approx. 300
watts |
|
|
|
|
|
|
Gewicht: |
45,3kg |
|
Breedte: |
482 mm |
|
Hoogte: |
241 mm |
|
Diepte: |
558 mm |
|
