DVDI-10 DVD/CD-Receiver (AM/FM), incl.
iPod-kabel |
| |
|
|
- High
Performance DVD / CD Player
- Multi-region compatible
- DAB/FM or FM/AM Tuner (Option:
DAB/FM module, incl. DAB-antenne)
- 1080p HDMI Output.
- Component Video / Scart / S-Video
- 2 x 75Watts RMS 8ohms.
- LFE Output
- i- Pod Control With Meta Data
Display
Entertainment
systems for all the senses.
Primare’s compact one-box systems
present the perfect blend of form
and performance, offering the
economy and sophistication of
Scandinavian design with the audio
and video integrity of our full size
models.
The DVDI10 uses an advanced modular
Class D amplifier, which draws from
music and film a sense of authority
that belies the 75 watt per channel
specifications. It generates very
little heat while being extremely
efficient, and so is perfectly
suited to ultra compact design. The
DVDI10 shares its video technology
with the high performance Primare
DVD26. We use a Primare-tuned high
quality CD/DVD drive in concert with
a superior video DAC and processing
technologies to get the most from
all the widely distributed CD and
DVD formats as well as MP3 files or
digital photos in JPEG format. The
DVDI10 offers a wide range of video
outputs to embrace numerous display
options, including HDMI, which
features up-scaling to Full HD
1080p. Connect your iPod® and
control selections from the DVDI10’s
remote and front panel display. You
can also select the DVDI10 with DAB
or FM radio.
|
Preamplifier
Analogue inputs |
|
|
Line inputs: |
RCA connector, 2.5V
RMS, 50KΩ. |
|
Front panel input: |
3.5mm jack plug,
2.5V RMS, 50KΩ. |
|
|
|
|
Analogue outputs |
|
|
PRE output: |
RCA connector,
variable output, 100Ω. |
|
REC output:
|
RCA connector, 2.5V
RMS, 100Ω. |
|
|
|
|
Digital outputs |
|
|
Optical output: |
TOSlink connector. |
|
Coax output: |
SPDIF (RCA connector),
75Ω. |
|
Sample Rate: |
44.1kHz with CD
playback,
48kHz with DAB receiver or line
inputs. |
|
|
|
|
DVD player |
|
|
Drive: |
Shinwa SHD-2503 |
|
Video signal systems: |
NTSC/PAL, color |
|
Video formats: |
> 500 lines |
|
HDMI output: |
480p/576p, 720p,
1080i, 1080p |
|
Progressive Scan component outputs: |
480p/576p |
|
Video output: |
1Vp-p, 75Ω RCA |
|
S-Video Y-signal: |
1Vp-p, 75Ω |
|
C-signal: |
0.286Vp-p, 75Ω |
|
Component video output: |
Y=IVp-p, B=0.7Vp-p,
R=0.7Vp-p, 75Ω |
|
RGB output: |
IVp-p, 75Ω |
|
Video signal-to-noise: |
-75dB |
|
Video DAC: |
Analogue Devices
ADV7320 |
|
Formats supported: |
CD, VCD, SVCD, CD-R,
CD-RW, DVD-R, DVD+R, MP3, JPEG |
| |
|
|
Amplifier |
|
|
Power output: |
2x75 W into an 8Ω
load. |
|
Class: |
Class D amplifier |
|
Distortion: |
20Hz–20kHz 10W below
0.1% THD+N. |
|
Frequency response: |
20Hz to 20kHz
±0.3dB |
| |
|
|
DAB receiver |
|
|
Tuning range: |
Band III 174-240MHz,
L-Band 1452-1492MHz |
|
Usable sensitivity: |
Band III 29dBuV,
L-Band 30dBuV. |
|
Number of presets: |
10 |
| |
|
|
FM tuner |
|
|
Frequency range: |
87.5-108MHz |
|
Usable sensitivity: |
FM Mono 10dBuV, FM
stereo 20dBuV |
|
Number of presets: |
40 |
|
Antenna: |
75Ω |
| |
|
|
AM tuner |
|
|
Frequency range: |
522–1620kHz |
|
Number of presets: |
40 |
|
Antenna: |
75Ω |
| |
|
| |
|
|
Color: |
black or titanium |
|
Weight: |
8kg |
|
Width: |
450 mm |
|
Depth: |
350 mm |
|
Height: |
110 mm |
|
 |
|
