> X2.5 voorversterker met afstandbediening



The X2.5 minimizes space requirements by reducing all components into a single machined chassis, bringing the analog section, power supply and menu display into one attractive package. The X2.5 shares the same input and output complement as the X1 and the X2.2. Each of these preamplifiers has one set of single-ended and one set of balanced outputs. Both sets of outputs may be used at the same time. The significant difference between the X2.5 and the X1 is the onboard power supply housed in the single chassis of the X2.5. Setting this aside, the sonic performance of the X2.5 is outstanding, offering a broad and deep soundstage, macro and micro dynamics not previously seen in preamplifiers of this price range, and a transparency that highlights the best features of source components and recordings. Variable gain settings in the X2.5 accommodate the needs of a diverse range of power amplifiers, making this compact preamplifier an excellent combination of space economy, value, and sonic performance…


Gain: selectable 4 dB or 14 dB balanced output,
selectable 4 dB or 14 dB single-ended output
Freq. Response: -3 dB @ 2 Hz, -3dB @ 100kHz
Distortion: < .1 % THD typically .003% @ 2 volts @ 1kHz
Max Output: 10 volts rms bal out, 7 volts rms unbal out
Output Impedance: 200 ohms unbalanced, 750 ohms balanced
Input Impedance: 33k ohm unbalanced, 66k ohm balanced
CMRR:  typical -55 dB, 1kHz
Crosstalk:  typical -85 dB, 1kHz
 Noise floor: < -125dBV, 20-20kHz
Output Noise: Ext. Amp turn on: 12 Volts DC mA continuous.
Power Consumption: 35 watts
Dimensions:

Gewicht: 12,7kg
Breedte: 431 mm
Hoogte: 89 mm
Diepte: 292 mm
